Solid State Logic XL-Desk OverviewLearn How to Record Audio for Video and FilmRead MoreThe Solid State Logic XL-Desk?with 16 E Series EQ Modules is a modern twist on the classic analog studio console. It’s designed for tracking or mixing engineers who require an analog console within a DAW-centric studio, but don’t want or need the integrated DAW control and analog level automation other SSL console products have. XL-Desk is in many ways a traditional 24 into 8 analog console, but it packs in a wide selection of features. It has 20 channel strips: 16 dual input mono (switchable between main input or DAW return) and 4 stereo channels. The first eight channels have VHD mic pre’s. There is an 18-slot 500-series rack built in that can be used for processing or mic pre’s. This version of the console comes loaded with 16 E Series EQ modules. XL-Desk ships with a legendary SSL Stereo Bus Compressor module in slots 17 & 18 (hard-wired to Mix A). The rack has its own dedicated power supply. There are four main Mix Busses (A, B, C, D) with Busses B, C and D able to be summed into Mix A. The Busses and channels can access the 500 racks, and each has a separate insert point for processing. There are two mono aux sends and two stereo return inputs. Direct outputs on every channel, stereo return and mix bus enable convenient stem printing. Each channel has a Cue Stereo Bus section (with Pan and Level) used to provide one of the headphone mixes while tracking. At mixdown, the mono channel DAW return signals can be routed to the CUE ST bus and then summed into Mix A. As a result, there are 16 main faders, 16 Cue ST inputs, and 4 Stereo channels, providing 40 summing inputs (using the stereo returns and insert sum functions you can squeeze in over 50 summing inputs). There is also a fully-featured monitoring section with bass management (3 sets of speakers + subwoofer), foldback A and B with individual talk-backs for headphone mixes, and a built-in Listen Mic input + classic compressor circuit, with its own direct output.Key Features20 + 1 fader, over 40 input SuperAnalogue SSL console8 built-in Variable Harmonic Drive (VHD) preamps16 dual-input mono channels (switchable between main input or DAW return)4 stereo channels (switchable to mono for tracking)The legendary Stereo Bus Compressor, with new high-pass filter sidechain18-slot 500 format rack built-in, accessible from channels or mix bussesIn addition to a 500 rack insert, each mono channel has a standard insert point4 stereo Mix Busses with their own insert points and access to the 500 rackOne stereo and 2 mono aux sends. Two dedicated stereo return inputsDirect outputs on every channel, stereo return, and mix bus for stem printingFully-featured monitoring section with bass managementFoldback A and B with individual talkbacks for headphone mixesBuilt-in Listen Mic input + classic compressor circuit, with its own direct outputAFL and Solo-In-Place solo modes, with Solo Clear and Solo Safe (Protect) modesBalanced D-Sub rear panel inputs/outputs & Front panel headphones & iJack socketsHigh quality internal PSU?In the BoxSolid State Logic XL-Desk Mixing Console with 16 E Series EQ ModulesLimited 1-Year WarrantyUser Manual6.5 MBSolid State Logic XL-Desk SpecsConnectionsPower Supply: IEC320 3-pin connector, 100 – 240 VAC, 50 – 60 Hz Analog I/O: 25-pin D-type socket, balanced, Zin > 10 kOhms, Zo ¡Ö 100 ohms, 3-pin XLR-M, balanced, Zo ¡Ö 100?ohms Headphones: Stereo 1/4″ jack socket, Zo ¡Ö 75?ohms iJack: Stereo 3.5 mm jack socket, Zi ¡Ö 10 k USB: 1 x type-B chassis socket (SSL diagnostic use only)PerformanceMaximum I/O Level: +18 dBu or 24 dBu Frequency Response: Line/Alt in to Channel Out (post): 20 Hz – 40 kHz (¡À0.2 dB) Line/Alt in to Mix bus (single fader): 20 Hz – 40 kHz (¡À0.5 dB) THD + N: < 0.05% (20 Hz - 20 kHz) Noise Line/Alt in to Channel Out (post): < -86 dBu (20 Hz - 20 kHz) Line/Alt in to Mix bus (single fader): < -83dBu (20 Hz - 20 kHz) THD + N: > +24 dBu (into 10 kOhms)Electro Magnetic CompatibilityEN55103-1:2009, EN55103-2:2009 Environment: E4 Initial in-rush current: 3.2 A 5 sec in-rush current: 3.2 A Braid-screened cables should be used where applicable Star Quad cables should be used where applicable EMC Performance Criteria Line level inputs and outputs Measure at mid-gain, noise <-56 dBuEnvironmentalTemperature Operating: +41 to 86 deg F (+5 to 30 deg C) Non-operating:-3 to 122 F (-20 to 50 deg C) Max. gradient: 59 F (15 deg C/hour) Relative Operating: 20 to 80% Humidity Non-operating: 5 to 90% Max. wet bulb: 84.2 deg F (29 deg C), (non-condensing) Vibration Operating: < 0.2 G (3 - 100 Hz) Non-operating: < 0.4 G (3 - 100 Hz) Shock Operating: < 2 G (10 ms max.) Non-operating: < 10 G (10 ms max.) Altitude Operating: 0 to 3000 m Non-operating (above sea level): 0 to 12000 mPower< 300 wattsDimensions(WxHxD) 40 x 9.9 x 32" (1015 x 251 x 812 mm)Weight89.5 lb (40.6 kg)Solid State Logic XL-Desk Solid State Logic XL-Desk Specs: Connections Power Supply: IEC320 3-pin connector, 100 - 240 VAC, 50 - 60 Hz Analog I/O: 25-pin D-type socket, balanced, Zin > 10 kOhms, Zo ¡Ö 100 ohms, 3-pin XLR-M, balanced, Zo ¡Ö 100?ohms Headphones: Stereo 1/4″ jack socket, Zo ¡Ö 75?ohms iJack: Stereo 3.5 mm jack socket, Zi ¡Ö 10 k USB: 1 x type-B chassis socket (SSL diagnostic use only) Performance Maximum I/O Level: +18 dBu or 24 dBu Frequency Response: Line/Alt in to Channel Out (post): 20 Hz – 40 kHz (¡À0.2 dB) Line/Alt in to Mix bus (single fader): 20 Hz – 40 kHz (¡À0.5 dB) THD + N: < 0.05% (20 Hz - 20 kHz) Noise Line/Alt in to Channel Out (post): < -86 dBu (20 Hz - 20 kHz) Line/Alt in to Mix bus (single fader): < -83dBu (20 Hz - 20 kHz) THD + N: > +24 dBu (into 10 kOhms)Electro Mag, Netic CompatibilityEN55103-1:2009, EN55103-2:2009 Environment: E4 Initial in-rush current: 3.2 A 5 sec in-rush current: 3.2 A Braid-screened cables should be used where applicable Star Quad cables should be used where applicable EMC Performance Criteria Line level Inputs and Output s Measure at mid- Gain, noise <-56 dBuEnvironmentalTemperature Operating: +41 to 86 deg F (+5 to 30 deg C) Non-operating:-3 to 122 F (-20 to 50 deg C) Max. gradient: 59 F (15 deg C/hour) Relative Operating: 20 to 80% Humidity Non-operating: 5 to 90% Max. wet bulb: 84.2 deg F (29 deg C), (non-condensing) Vibration Operating: < 0.2 G (3 - 100 Hz) Non-operating: < 0.4 G (3 - 100 Hz) Shock Operating: < 2 G (10 ms max.) Non-operating: < 10 G (10 ms max.) Altitude Operating: 0 to 3000 m Non-operating (above sea level): 0 to 12000 m Power< 300 watts, Dimensions: (WxHxD) 40 x 9.9 x 32" (1015 x 251 x 812 mm) Weight: 89.5 lb (40.6 kg) Contact UNCUCO WhatsApp: +8615989288128 Email:service@uncuco.com
Payment Method
We accept online payments via paypal, credit and debit cards. We also accept western union, money gram and bank transfer.
To order goods online and pay them via paypal, credit and debit cards, simply add your selected items to your basket, and proceed to the checkout, where you will be guided through the payment process.
Payment via PayPal:
1. You have your PayPal account, then choose the PayPal to complete the payment directly
2. If you want to use the PayPal payment, but you don’t have one PayPal account, please register one first.
Note: Choose the PayPal payment, you can choose your country currency, we accept all the currency.
Payment via Debit and Credit Card:
1. You click MasterCard, Visa Credit Card, American Express, Discover payment directly, you will be redirected to the PayPal website, then choose the payment method again, and fill in your card information to complete the payment.
2. You click the PayPal&Credit, you will be redirected to the PayPal website, the one is PayPal payment, the other one is Pay with Debit or Credit Card payment. Choose one to complete the payment.
Note: Your credit card will be charged upon placement of your order.
Payments via Western Union, Money Gram and Bank Transfer
If you would like to place your order, please contact us with the following information:
E-mail: service@uncuco.com
WhatsApp: +8615989288128
Your billing and delivery address.
Your full name, phone number and email address.
The list of items you'd like to purchase.
We will get back to you with a proforma invoice, and the directions for the final step to complete the direct deposit.
The payment needs to be verified by our in-house accounts department and goods will only be dispatched on their verification. Only once the funds have reflected in our bank account, will the goods be allowed to leave the store.
Please note that bank transfer transactions can take up to 4 business days to clear into our account. We will process your order as soon as your payment has cleared. To ensure a speedy turn around time, please notify us once you have made the deposit.
We offer cardholders the highest level of security in online shopping, irrespective of the type of card (credit or debit). All debit or credit card payments are processed via Activa System’s Secure Payment Gateway. All payment card information is entered exclusively on the bank’s 3D secure pages. We as the merchant do not store, have access to or sight of the payments card information. Should you select to pay with a payment card, you will therefore be redirected to secure pages administered by the Activa processing centre and a bank with which we have reached a card acceptance arrangement.
Verified by Visa & Mastercard
The Verified by Visa and MasterCard SecureCode trademarks displayed above allow each online purchase made with your payment card to receive additional protection via 3D Secure security protocols. 3D Secure is a unique service offered by MasterCard and Visa International that uses a One Time Pin (OTP) to protect a cardholder against unauthorized use of their card. Once activated, your card number cannot be used for online purchases at participating merchants without your One Time PIN (OTP). The OTP is sent to your cell phone during payment as the final step to complete the transaction.
SHIPPING AND DELIVERY
Shipping prices will be calculated at check-out, based on the weight of the goods, the country to which we are dispatching, and the shipping service you choose. If you place the order offline by email or phone, we will send you a proforma invoice including the shipping prices.
When will I receive my order?
The likely delivery timescale for orders will depend on the availability of the items you order, the delivery method you choose (where applicable) and the shipping destination country.
Delivery times can be calculated based on formula: Time to stock + 7days~15days ( The time shipping company needs deliver the products to address in your country)
Time to stock is the number of days we need to prepare your order for shipment or how long manufacturer or supplier needs to deliver the product to our warehouse.
Delivery tracking
We use DHL or Fedex or UPS or EMS express service for our deliveries. The tracking number will be sent to you by email as soon as we will ship the order. Please note that no information will be available for the tracking number until the shipping company has actually picked up the package. Please allow up to one business day for tracking information to become available. All deliveries require a signature.
Please note
We are only able to dispatch goods once payment has been received.
All orders are subject to approval by our verification department. We will notify you by phone or email should your order be delayed.
If, for any reason, we cannot supply a product you have ordered, we will contact you via email or phone and place your product/s on back-order once you have agreed you would like to wait. If you choose to put your order on back-order, we will provide you with personalized weekly updates and will notify you once your order has shipped. If one or more of your items is in stock and you are waiting on other item/s, you can have your order part shipped. A sales representative will keep you updated on the remaining portion of your order, and can provide tracking information for both shipments.
