Hear the sonic consistency of DPA microphonesThe black?DPA?4061 CORE Low-Sensitivity Omni Lavalier Microphone Stereo Instrument Kit with Accessories?is a?discreet, flexible microphone solution aimed at project studios and production companies seeking a flexible microphone system for in-studio and on-stage events.The kit includes a pair of miniature, moisture-resistant mics for use with wired or wireless systems for broadcast, performance, and theatrical applications. The kit also features a comprehensive set of accessories, including several mounting options along with windscreens, XLR adapters, and protective cases.?To provide accurate stereo recording, the two omnidirectional condenser microphones are hand-selected for matched sensitivity within ¡À1.5 dB.Each electret-condenser capsule delivers accurate instrumental recordings and crisp, clear, and intelligible speech, while the rugged yet unobtrusive design is well suited to the demands of professional live stage work. This version of the 4061 uses DPA’s CORE technology to deliver a 4 dB increase in dynamic range and a 14 dB reduction in noise over?the 4061 Legacy model.?The included High-Boost Grid offers a 10 dB boost around 12 kHz, especially helpful when the lav is used for chest placement.With an SPL rating of 144 dB, each microphone is more than capable of handling a wide variety of instruments as well as loud performers, vocalists, and presenters¡ªmaking the kit a flexible tool for houses of worship and live event productions.The 4061 CORE can be powered by 5 to 10V plug-in power from a wireless transmitter and features a modular design using a Microdot output connector. The mic is compatible with various wireless microphone transmitters via a separately available adapter for the compatible transmitter.This stereo instrument kit includes two XLR adapters for use with a wide variety of professional equipment. The adapter allows the mic to be powered via 12 to 48V phantom power. Also included are two clips to mount the mic to stringed instruments, two boundary layer mounts, two surface mounts with pieces of adhesive tape, two magnet mounts, an inner plastic case, and a zippered traveling case.Modular System Featuring Microdot Connector with Adapter OptionsCompatible Wireless TransmittersVarious:?Works with various transmitters via a compatible adapter (available separately).The modular design allows you to adapt the 4060’s Microdot connector to a wide variety of transmitters simply by purchasing the compatible adapter¡ªsaving you the expense of buying another microphone.Included XLR Adapter for Wired ApplicationsThe DAD6001 Microdot to 3-pin XLR Adapter allows you to power the 4061 from 12 to 48V phantom power for wired applications.A Reliable, Broadcast-Quality LavalierMiniature Mic with a Crisp, Clear SoundThe 4061 CORE features a 5.4mm capsule that enables the microphone to be inconspicuous and easily disguised in clothing or costumes. The vertical diaphragm design offers a clear and natural sound optimized for the human voice.High-Boost Grids Included to Tailor High FrequenciesThe included High-Boost Grids introduce a 10 dB boost around 12 kHz for applications where chest-placement is preferred. The grids are made of tough and scratch-resistant anodized stainless steel, allowing them to be detached and cleaned.Additional Headroom for Loud Instruments & VocalsThe 4061 CORE features a less sensitive capsule designed to handle loud instruments and vocals at levels up to 144 dB SPL before clipping. This also makes the mic well suited to concealment in clothing and costumes and allows the mic to be hidden at the subject’s hairline without overloading the input levels.Omnidirectional Polar PatternThe forgiving omnidirectional pickup pattern captures sound from all around the mic and provides a consistent frequency response, even for off-axis sound. This helps to supply clear, intelligible speech and vocals, even when the talent turns away from the microphone.Tough, Moisture-Resistant ConstructionEngineered with a double-vent protection system, the 4060 is certified IP58 for dust and moisture resistance. The rugged 5.9′ cable is built with Kevlar strain relief to survive the constant twists, bends, and pulls that are part of everyday use in harsh environments.Included Instrument Mounts and AccessoriesTwo BLM6000 Boundary Layer Mounts: Used with the 4060, 4061, 4062, and 4063 miniature microphones to place on a reflective boundary such as a floor, wall, ceiling, piano lid etc. This enables the mics to capture the ambient sound of the area. The sound captured from this ¡°pressure zone¡± has higher sensitivity, clarity, and intelligibility compared to the sound captured from the “free air”, with this solution serving as a kind of acoustical zoom.Five DMM0007 Universal Surface Mounts: This mount allows the mic to be mounted in the best-sounding position for a wide variety of instruments, from acoustic guitar through grand piano and drums. The mount uses special non-marking adhesive discs for attachment.Two MHS6005 Lavalier Microphone holders for string instruments: Made from soft rubber, these are used to attach the mic to a violin, viola, cello, or double bass. The holder is mounted between the tailpiece and the bridge and can be turned upwards or downwards so that the mic will be placed either over or under the strings, depending on the desired sound color or sound level. The lav mic is secured by its cable in a little clip, while the holder itself has a firm grip on two strings of the instrument with small hooks.Five foam windscreens to reduce wind and breath noise for speech and vocal applicationsTwo magnet mounts are supplied that allow you to mount the mic on clothing.Additional OptionsAdditional mounting options are available separately:The SCM0032-B 2-Way Dual Clip allows you to mount two lavs for broadcasting.The SCM0013-B 4-Way Clip offers a variety of flexible positioning choices for up, down, left, and right mounting.To hide the mic, the?DMM0021?Concealer attaches safely and securely to clothing and costumes and is designed to resist clothing and rustling noise.
DPA Microphones d:screet Core 4061 SpecsMicrophonePrimary ApplicationsLive Sound, Studio Recording, Broadcast, ENG (Electronic News Gathering), Audio for Video, Location Sound, Corporate PresentationForm FactorLavalierIntended Sound SourcesVocals, Acoustic Guitar, Electric Guitar, Electric Bass, Acoustic Bass, Piano, Percussion, Instrument, Flute, Strings, Violin, Viola, Cello, Choir, Room AmbianceSound FieldMonoOperating PrinciplePressure OperatedCapsuleCondenserDiaphragm0.2″ / 5.4?mm Polar PatternOmnidirectionalHigh-Pass FilterYesWindscreenFoam (Included)PerformanceFrequency Range20 Hz to 20 kHz Maximum SPL137 dB SPL Peak (Plug-In Power, 1% THD)144 dB SPL Peak (Plug-In Power, 10% THD)Impedance40 OhmsSensitivity6 mV/Pa at 1 HzDynamic Range111 dB A-WeightedEquivalent Noise Level38 dB ITU-R 468 (Typical)THD< 1% ConnectivityOutput Connectors (Analog)1 x Microdot Coaxial Male (Locking)Headphone ConnectorNoneCable Length5.9' / 1.8?mPowerBus PowerNoneOperating Voltage5 to 10 V (Plug-In Power)12 to 48 V (Phantom Power)Operating Current Consumption1.5 mAPhysicalColorBlackMountingInstrument Clamp, Instrument Surface Mount, Magnetic Mount, Surface-Mount (Included)Included CaseHard Case, Zipper PouchOperating Temperature-40 to 113¡ãF / -40 to 45¡ãCOperating Humidity0 to 90%Weight0.26?oz / 7.5?gPackaging InfoPackage Weight1.125 lbBox Dimensions (LxWxH)9.7 x 5.9 x 2.8"S
