Ideal for orchestral recording and live stage applications, the matte black Neumann KM 184 MT Octo Set features eight KM 184 MT small-diaphragm cardioid condenser microphones, each with a foam windscreen, a stand adapter, and a mic pouch. The KM 184 MT offers premium Neumann sound that’s both open and musical without imparting its own sonic signature, making it a popular choice for solo instruments and ensembles where microphone transparency is a top priority.The transformerless circuitry and balanced output result in high-output gain with an ultralow noise floor. The mic’s uniform cardioid Polar pattern provides a targeted pickup area with no off-axis coloration while handling SPLs up to 138 dB, allowing confident close-miking of instruments. As with true condenser mics, the KM 184 is powered via +48V phantom power.Cardioid Polar PatternThe cardioid Polar pattern effectively isolates signal source.KM 100-Based Output StageThe KM 184 features the same output stage electronics as the KM 100. Transformerless circuitry and quiet balanced output design ensure a clean, high-gain output signal without any coloration. The KM 184 is powered via +48V phantom power, and its 20 Hz to 20 kHz frequency response provides flexibility for use in a wide range of recording situations. The KM 184 can handle sound-pressure levels up to 138 dB, allowing fairly close miking of instruments.Compact Rugged ConstructionThe slim design and rugged construction allow easy microphone placement while remaining roadworthy.WhatsApp:+8615989288128, UNCUCO Radio / TV Studio Equipment 615104083899
Neumann KM 184 OCTO SET SpecsMicrophoneOperating PrinciplePressure GradientCapsuleCondenser Polar PatternCardioidPerformanceFrequency Range20 Hz to 20 kHz Maximum SPL138 dB SPLImpedance50 OhmsLoad Impedance1000 OhmsSensitivity15 mV/Pa at 1 kHz into 1 KilohmsSignal-to-Noise Ratio72 dB CCIR81 dB A-WeightedEquivalent Noise Level22 dB CCIR13 dB A-WeightedTHD0.5% ConnectivityOutput Connectors (Analog)1 x XLR 3-PinPowerOperating Voltage48 V ¡À 4 VOperating Current Consumption3.2 mAPhysicalDimensions?: 0.87 x L: 4.21″ / ?: 22 x L: 107?mmWeight2.82?oz / 80?gPackaging InfoPackage Weight0.55 lbBox Dimensions (LxWxH)9.85 x 3.2 x 2.5″S
