Ian Kelly about the KM 184 and the TLM 103Designed as a budget-friendly alternative to the heralded U 87 microphone for project studios, producers, and vocalists, the black Neumann TLM 103 MT Stereo Set is a pair of large-diaphragm condenser mics offering the classic Neumann sound with elevated presence to impart a crisp, clean, and full tone. It boasts a capsule based on the U 87 married to pristine transformerless circuitry, allowing it to handle high SPLs up to 138 dB without distortion while maintaining superbly quiet self-noise of just 7 dBA. The combination of the transformerless output stage and heightened treble response makes the TLM 103 a great choice when the sound source needs to clearly cut through the mix. The mic’s compact body is ideal for positioning it in tight spots such as over a snare, inside a kick drum, or in front of a small guitar amp. By utilizing a cardioid polar pattern, the mic can effectively reduce ambient noise or instrument bleed behind the mic. The TLM 103 MT Stereo Set comes with two color-matched shockmounts and an aluminum case, making it well suited to use in the studio or on stage.Affordable Alternative to the U 87Introduced in 1997 as an affordable alternative to the venerable U 87, the TLM 103 has since become a classic in its own right. Today, the TLM 103 defines the standard by which contemporary studio microphones are measured. Its classic, tapered headgrille design gives the TLM 103 a distinct Neumann look.Large-Diaphragm CapsuleThe TLM 103 is a cardioid microphone with a large-diaphragm condenser capsule derived from the classic K67/87 capsule of the legendary Neumann U 87. However, the TLM 103 has a slightly more modern voicing with a wide presence boost for frequencies above 5 kHz.Refined and Full SoundIts very direct yet refined sound is perfect for vocals and solo instruments that pop out of the mix without effort. Of course, the TLM 103 also has the famous authoritative midrange that has become the hallmark of Neumann microphones and made them a top choice in studios around the world. A special feature of the TLM 103 is its impressively deep yet controlled low end, perfect for sonorous voices and powerful bass instruments.Technical ExcellenceWith an incredibly low self-noise of only 7 dBA, the TLM 103 is among the quietest microphones available. And its high sensitivity of -32.5 dBV ensures ultralow noise, even with budget preamps and audio interfaces or vintage tube equipment. At the same time, the TLM 103 can handle enormous sound pressure levels of up to 138 dB without the need for pre attenuation. Its vast dynamic range of 131 dB makes the TLM 103 a very easy-to-use studio microphone as it will capture anything from a soft whisper to a thunderous bass drum without adding noise or distortion.Transformerless OutputAs a member of Neumann’s TLM series, the TLM 103 works with a transformerless output stage, which minimizes transmission losses and ensures a very immediate, uncolored sound, true to the original as well as a clear, powerful bass response, even at highest signal levels.ApplicationsThe TLM 103 was primarily designed for project studios and broadcast use, but due to its outstanding performance was soon embraced by renowned studios as a more modern sounding alternative to the U 87 for speech, vocals, drums, guitar amps, and piano. The TLM 103 is also often used as a spot mic in classical recordings for cello and double bass.Features at a GlanceLarge-diaphragm condenser capsule derived from the classic U 87 microphoneBalanced sound with enhanced presenceCardioid pattern reduces background noiseTransformerless circuitry with high SPL capabilityExtremely low self-noise of only 7 dBAXLR 3-pin output48V phantom poweredIncludes two black shockmounts and aluminum caseWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 615104085022
Neumann TLM 103 SpecsMicrophonePrimary ApplicationsStudio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePadNoneHigh-Pass FilterNoneTone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsNoneWindscreenNonePerformanceFrequency Range20 Hz to 20 kHz Maximum SPL138 dB SPL (.5% THD)Off-Axis Rejection>2 dB at 60¡ã>10 dB at 120¡ã>25 dB at 180¡ãImpedance50 OhmsLoad Impedance1000 OhmsSensitivity-32.5 dBV at 1 kHz into 1 KilohmsOutput Level13 dBu (Max)Dynamic Range131 dB A-WeightedSignal-to-Noise Ratio76.5 dB CCIR87 dB A-WeightedEquivalent Noise Level7 dB A-Weighted17.5 dB CCIRConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerBus PowerNoneOperating Voltage48 V ¡À 4 V (Phantom Power)Operating Current Consumption3 mAPhysicalColorBlackMountingShockmount (Included)Included CaseHard CaseIncluded FiltersNoneDimensions?: 2.4 x L: 5.2″ / ?: 6 x L: 13.2?cmWeight15.87?oz / 450?gPackaging InfoPackage Weight10.06 lbBox Dimensions (LxWxH)16 x 14 x 7″S
