Continuously playback audio files just like a CD changer
Professional CD player that supports SD/SDHC cards and USB
The CD-200SB is a new line-up to the popular CD-200 series that have been installed in countless facilities.
It is a professional CD player with SD/SDHC and USB memory device playback support.
This model has been discontinued in North, Central and South America.
Please check the availability with your local distributors in other areas.
Direct access to 10 folders via 10 front-panel buttons
The biggest feature of CD-200SB is its solid-state player that offers operability akin to that of a traditional CD changer.
The number buttons allocated on the front panel offer direct access to 10 user-defined folders contained within SD/SDHC and USB media.
The CD dubbing function enables users to select an album and playback an audio file as like with a CD changer, after having set up their individual audio file folders similar to albums.
Due to the removal of the rotating mechanism, the solid-state media player is highly durable and does not require maintenance.
As such, users can use the CD-200SB to play BGM for hours on end every day without concern.
Includes a high-quality CD drive specialized for audio developed internally by TEAC
The solid-state player, in addition to the CD-player, include specifications and functions that meet the requirements for installed sound application.
The CD drive employs the audio CD drive that has been developed internally by TEAC and also includes a shock-proof function.
The CD-200SB plays data CDs as well as audio CDs, offering a high level of versatility and reliability.
The CD-200SB encompasses a new concept for professional CD players that demonstrates compatibility with both traditional CD media and solid state media, currently seeing rapid spread as the new generation of music media, while still being as easy to use as any familiar CD-changer.
Features at a glance
- SD/SDHC, USB playback
- Direct access to 10 user defined folders configured within SD/SDHC and USB media
- Dubbing from CD to memory storages (WAV or MP3)
- Playback format:
- CD: CD-DA, WAV, MP3, MP2
- SD/SDHC, USB: WAV, MP3, MP2, WMA, AAC
- CD Text and ID3/WMA/AAC tag display
- Four playback modes: continuous, shuffle, single and program
- Repeat playback modes
- Folder repeat playback mode for data CDs, SD/SDHC and USB
- Various time display (CD-DA: Track elapsed, track remain, total remain others: Elapsed)
- +/- 14.0 % pitch control for CD
- Intro check
- Shock-proof memory (up to 10 sec)
- RCA unbalanced output
- XLR balanced output
- RCA coaxial and Optical digital outputs
- EIA 2 U Rack mount size
- Wireless Remote controller included
- Headphone Output (1/4”)
- ROHS Certified
Spec description
Playback media | SD/SDHC card、USB flash-drive、CD-DA、CD-R、CD-RW |
Playback format | |
WAV (Data CD, SD/SDHC, USB) |
Stereo, 8kHZ – 48kHz、8/16bit |
MP3 (Data CD, SD/SDHC, USB) |
Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz、8 – 320kbps、VBR |
CD-DA | Stereo, 44.1kHz、16bit |
MP2 (Data CD, SD/SDHC, USB) |
Stereo, 16/32/22.05/44.1/24/48kHz、8 – 384kbps、VBR |
WMA(SD/SDHC, USB) | Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz、8-320kbps, VBR |
AAC(SD/SDHC, USB) | Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz、8 – 320kbps、VBR |
Number of channels | 2 channel (stereo) |
Recording format | |
WAV | 44.1kHz, 16bit |
MP3 | 44.1/48kHz, 64/128/256kbps |
ANALOG OUT | |
unbalanced | RCA |
Nominal output level | -10dBV |
Maximum output level | +6dBV |
Output impedance | 200Ω |
balanced | XLR-3-32(1:GND、2:HOT、3:COLD) |
Nominal output level | +4dBu |
Maximum output level | +20dBu |
Output impedance | 200Ω |
PHONES OUT | 6.3mm(1/4″) stereo phone jack |
Maximum output level | 20mW + 20mW (THD 0.1%, 32Ω loaded) |
DIGITAL OUT | |
COAXIAL | RCA |
Output impedance | 75Ω |
Compatible signal format | IEC60958-3 (S/PDIF) |
OPTICAL | TOS (JEITA RC-5720C) |
Compatible signal format | IEC60958-3 (S/PDIF) |
Power source | US, Canada:120V AC, 60Hz / EUR:230V AC, 50Hz / Australia:240V AC, 50Hz |
Power consumption | 11W |
Size (W x H x D)mm | 481 x 94.5 x 298 |
Weight | 4.7kg |
Audio performance | |
Frequency response | 20Hz – 20kHz, +/-1.5dB (playback, JEITA) |
THD | Less than 0.01% (playback, JEITA) |
S/N ratio | 90dB or greater (playback, JEITA) |
Dynamic range | 990dB or greater (playback, JEITA) |
Channel separation | 90dB or greater (playback, JEITA) |
CD-200SB Tested media List
SD™/SDHC™ |
Last update:July 29, 2015 |
Maker | Series | Model | Capacity | Result |
SanDisk | SanDisk Extreme PRO® SDHC™ UHS-I Memory Card (U3, Class10) |
SDSDXPA-032G-JU3 | 32GB | OK |
SDSDXPA-016G-JU3 | 16GB | OK | ||
SanDisk Extreme® SDHC™ UHS-I Memory Card (U3, Class10) |
SDSDXL-032G-JU3 | 32GB | OK | |
SDSDXL-016G-JU3 | 16GB | OK | ||
SanDisk® SDHC™ Memory Card (CLASS4) |
SDSDB-008G-J01 | 8GB | OK | |
Sony | SDHC™ Memory Card UHS-I CL10 (U3, Class10) |
SF-32UX2 | 32GB | OK *1 |
TOSHIBA | EXCERIA™ UHS-I SDHC™ Memory Card (U3, Class10) | SD-JU032G | 32GB | OK |
SD-JU016G | 16GB | OK |
Maker | Series | Model | Capacity | Result |
SanDisk | SanDisk Extreme PRO® SDHC™ UHS-II Memory Card |
SDSDXPB-032G-J35 | 32GB | OK |
SDSDXPB-016G-J35 | 16GB | OK | ||
SanDisk Extreme PRO® SDHC™ UHS-I Memory Card (Class10) |
SDSDXPA-032G-J35N | 32GB | OK | |
SDSDXPA-016G-J35N | 16GB | OK | ||
SanDisk Extreme Pro® SDHC™UHS-I Card |
SDSDXP1-032G-J95 | 32GB | OK | |
SDSDXP1-008G-J95 | 8GB | OK | ||
SanDisk Extreme® PLUS SDHC™ UHS-I card (Class10) |
SDSDXS-032G-J35P | 32GB | OK | |
SDSDXS-016G-J35P | 16GB | OK | ||
SanDisk Extreme® SDHC™ UHS-I Card (Class10) |
SDSDXL-032G-J35 | 32GB | OK | |
SDSDXL-016G-J35 | 16GB | OK | ||
SDSDXS-032G-J35 | 32GB | OK | ||
SDSDXS-016G-J35 | 16GB | OK | ||
SDSDXS-008G-J35 | 8GB | OK | ||
SDSDX-032G-J35 | 32GB | OK | ||
SDSDX-016G-J35 | 16GB | OK | ||
SDSDX-032G-J95 | 32GB | OK | ||
SDSDX-016G-J95 | 16GB | OK | ||
SDSDX-008G-J95 | 8GB | OK | ||
SDSDX-004G-J95 | 4GB | OK | ||
SanDisk Ultra® PLUS SDHC™ UHS-I Memory Cards (Class10) |
SDSDUP-016G-J35 | 16GB | OK | |
SDSDUP-008G-J35 | 8GB | OK | ||
Lexar | Lexar® Professional 133x SDHC™ Card (Class10) |
LSD8GBDRBJP133 | 8GB | OK *1 |
Lexar® Platinum II SDHC™ UHS-I Card (Class10) |
LSD8GBBBJP200C10 | 8GB | OK | |
Lexar® Platinum II 100x SDHC™ Card |
LSD32GBCJP100 | 32GB | OK *1 | |
LSD8GBBCJP100 | 8GB | OK *1 | ||
LSD4GBBCJP100 | 4GB | OK *1 | ||
Standard SDHC™ Card (Class4) |
LSD32GACJP | 32GB | OK *1 | |
LSD16GACJP | 16GB | OK *1 | ||
LSD8GBACJP | 8GB | OK *1 | ||
Super Value SDHC™ Card (Class4) |
LSD8GBASVDJP | 8GB | OK *1 | |
LSD4GBASVDJP | 4GB | OK *1 | ||
Panasonic | SDHC Card (UHS-I / Class10) R:95MB/s W:80MB/s |
RP-SDA32GJ1K | 32GB | OK |
RP-SDA16GJ1K | 16GB | OK | ||
RP-SDA08GJ1K | 8GB | OK | ||
SDHC (UHS-I / Class10) R:90MB/s W:45MB/s |
RP-SDUC32GJK | 32GB | OK *1 | |
SDHC Card (UHS-I / Class10) R:90MB/s W:25MB/s |
RP-SDU32GJ1K | 32GB | OK | |
RP-SDU16GJ1K | 16GB | OK | ||
RP-SDU08GJ1K | 8GB | OK | ||
SDHC Card (Class10) R:20MB/s |
RP-SDWA16GJK | 16GB | OK | |
RP-SDWA08GJK | 8GB | OK *1 | ||
RP-SDWA04GJK | 4GB | OK *1 | ||
SDHC Card (Class6) R:20MB/s |
RP-SDLC32GJK | 32GB | OK | |
RP-SDLC16GJK | 16GB | OK | ||
RP-SDLC08GJK | 8GB | OK | ||
RP-SDLC04GJK | 4GB | OK | ||
SD Card (Class4) 20MB/s | RP-SDL02GJ1K | 2GB | OK |
*1 There is no problem in the content of the recording though the monitor sound might become interrupted when copying by “WAV file”(CD->SD/USB).
USB memory |
Last update:July 21, 2015 |
Maker | Series | Model | Capacity | Result |
I-O DATA | U3-MAX | U3-MAX16G/K | 16GB | OK |
SanDisk | Cruzer Fit™ | SDCZ33-064G-J57 | 64GB | OK |
SDCZ33-032G-J57 | 32GB | OK | ||
SDCZ33-016G-J57 | 16GB | OK *1 | ||
Silicon Power | Ultima U06 | SP016GBUF2U06V1B | 16GB | OK *1 |
SP008GBUF2U06V1B | 8GB | OK *1 |
Maker | Series | Model | Capacity | Result |
ELECOM | MF-MSU3A | MF-MSU3A64GBK | 64GB | OK |
MF-MSU3A32GBK | 32GB | OK | ||
GREEN HOUSE | GH-UFD3-*D | GH-UFD3-64GD | 64GB | OK |
GH-UFD3-32GD | 32GB | OK | ||
GH-UFD3-16GD | 16GB | OK | ||
Lexar | JumpDrive S73 USB3.0 | LJDS73-64GACJP | 64GB | OK *1 |
LJDS73-16GACJP | 16GB | OK *1 | ||
JumpDrive S70 USB Memory | LJDS70-64GACJP | 64GB | OK | |
SanDisk | Extreme | SDCZ80-064G-X46 | 64G | OK |
Cruzer | X000316PNF | 32G | OK *1 | |
X0002KTR5R | 16G | OK *1 | ||
SANWA SUPPLY | UFD-SL*N | UFD-SL4GBKN | 4GB | OK |
UFD-SL2GBKN | 2GB | OK | ||
UFD-SL1GBKN | 1GB | OK | ||
SONY | USM-R | USM64GQX B | 64GB | OK |
USM32GQX B | 32GB | OK | ||
USM16GQX B | 16GB | OK | ||
USM8GQX B | 4GB | OK | ||
Transcend | JetFlash 760 | TS16GJF760 | 16GB | OK *1 |
TS4GJF760 | 4GB | OK | ||
JetFlash 350 | TS8GJF350 | 8GB | OK *1 | |
TS4GJF350 | 4GB | OK *1 |
*1 There is no problem in the content of the recording though the monitor sound might become interrupted when copying by “WAV file”(CD->SD/USB).
*3 There is no problem in the content of the recording though the monitor sound might become interrupted when copying by “WAV file”(CD > SD/USB).
