Mic Shootout 1: Classic Large Diaphragm CondensersRead MoreSepultura – Stanley Soares – Studio engineer interview – AKG C414AKG C 414 B-XLII – Promotion videoMic Shootout 1: Classic Large Diaphragm CondensersThe AKG C414 XLII Microphone and Universal Audio LA-610 Recording Kit from UNCUCO includes the AKG C414 XLII multi-pattern large-diaphragm condenser microphone, a Universal Audio LA-610 MKII recording channel, a Mogami Gold Studio XLR microphone cable, an H 85 universal shock mount, a W414X microphone windscreen, a PF80 universal pop filter, an AC power cord, and a metal carrying case. This versatile kit can be used for capturing audio, tailoring it accordingly using EQ and a T4 opto-compressor as a front-end for tracking into a digital audio workstation.AKG C414 XLII Large-Diaphragm Multipattern Condenser MicrophoneThe AKG C414 XLII Large-Diaphragm Multipattern Condenser Microphone is an industry staple that extends the renowned heritage of the C414 B-TL II. Equipped with nine selectable polar patterns, three attenuation levels, and three switchable bass-cut filters, the C414 XLII remains one of the most versatile condenser microphones for recording vocals, drums, and acoustic and amplified instruments in the studio or on stage. This microphone is designed to closely approximate the sonic character of the vintage C12 tube mic while providing an updated and expanded feature set. A slight high-frequency rise at 3 kHz and above helps compensate for the natural loss of high frequencies that occurs at a distance, making the C414 XLII an excellent choice for miking vocals & instruments that are positioned far away. The 1″ edge-terminated, dual-diaphragm transducer combined with the low-noise electronic circuitry provide a wide dynamic range of 134 dB and can handle SPL up to 158 dB, for a detailed, linear, and natural tone. With full immunity to electromagnetic and electrostatic interference as well as high tolerance to humidity, the C414 XLII is well suited to withstand the rigors of demanding studio, stage, and broadcast applications. Special features include a peak-hold LED to alert you if overloading occurs, and a lock mode that prevents unintended changes to the microphone settings. The package includes a vibration-inhibiting shockmount, a pop filter, a windscreen, and a metal carrying case.AKG’s Legendary 1″ Large-Diaphragm CapsuleThe legendary C414 is a tool found in most recording studios and has been used on thousands of hit records; it’s been on stage with artists of every musical genre and is also used by leading broadcast facilities the world over. The C414 family has been one of the world’s most widely used and respected studio and stage microphones in audio history. Added useful features and even greater ease of use make the XLII a worthy member of the renowned C414 line. The C414 XLII is the successor of the famous C414 B-TL II. It shows the sonic signature of the highly sought-after AKG C12, which enables lead vocals and solo instruments to be placed even in a dense mix. The unrivaled up-front sound is also well known for distant miking applications like classical music recording or drum ambience miking.Nine Selectable Polar PatternsThe C414 XLII is the multi-instrumentalist in your microphone rig ready to fill in wherever needed. Whether it’s omni, wide cardioid, cardioid, hypercardioid, figure-8, or the four intermediate polar patterns, there are plenty of ways to get the most natural sound from any instrument¡ªelectric and acoustic guitars, drums, and much more. Employ a hypercardioid pattern to reduce drum spill, then quickly switch to a figure-8 pattern to balance out two vocalists. These easy-to-access options make the AKG C414 XLII suitable to any studio with limited space in its mic locker.Overload-Detection LED and Bass-Cut FilterThe AKG C414 XLII empowers you to make better recordings. When acting as both artist and engineer, the mic’s overload-detection LED makes it easy to see when your input levels are too high. This helps you take full advantage of the mic’s dynamic range and only engage the pad when necessary. Its bass-cut filter helps you curb rumbles, vibrations, and loud, boomy sounds and minimizes the proximity effect for balanced recordings. For live sound applications and permanent installations, all controls can easily be disabled for trouble-free use.Rugged Metal HousingThe all-metal body ensures efficient rejection of RF interference so you can use the microphone near transmitter stations, along with wireless microphones or other communications equipment.Features at a GlanceMaintains the sonic character of the legendary C12Successor of the C414 B-TL IIAcoustic resistor provides a slight high-frequency rise at 3 kHz and above1″ edge-terminated capsule with dual diaphragms sputtered in gold on one sideNine selectable polar patterns for every application158 dB maximum SPL (-18 dB pad on)Switchable pad (-6, -12, or -18 dB) and low-cut filter (40, 80, or 160 Hz)Integrated capsule suspension to reduce mechanical noiseCompletely immune to electrostatic and electromagnetic interferenceAll switchable components operate in low-impedance circuits for ultrahigh reliability even in extremely humid conditionsOperates on 48V phantom power (accepts 44 to 52 VDC phantom power)XLR 3-pin output connectorIncludes metal carrying case, shockmount, windscreen, and pop filterWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 885038025924Universal Audio LA-610 MKII Recording ChannelThe LA-610 Mk II from Universal Audio brings vintage all-tube sound to the modern channel-strip format. The unit combines a 610 Mic-Pre / EQ / DI section based on console modules developed by Bill Putnam in the 1960s, with a T4 Opto-compressor, and houses them in a 2 RU rackmount enclosure. The 610-tube preamp, DI and EQ deliver a sound that is as timeless as it is legendary, and a hallmark of many classic recordings. The simple operation and program dependent nature of the T4 compressor provides extremely musical control.The LA-610 MkII is sonically very versatile and can function as an ideal front-end for tracking into a digital audio workstation. The preamp is augmented with two bands of shelving EQ, followed a T4 based optical compressor. Although not an exact LA-2A clone, the compressor circuitry nevertheless shares its signature sound by utilizing its unique combination of an electro-luminescent panel and photo-resistors. Three 12AX7A tubes, a single 6072A and 6AQ5 tube combine to provide warmth and overall even tonal balance.The Mk II delivers several enhancements over the original LA-610. A true compressor bypass switch is now available which completely avoids the compressor circuitry. Other changes improve the performance of the output signal, improved consistency with input gain values and feedback-style shelving EQ improves the EQ stability. An auto-sensing, universal power supply is included, along with larger and better lit metering.Single-channel vintage channel-strip Design based on legendary Bill Putnam’s 610 tube microphone preamp and EQ console modules, used on countless classic recordingsMicrophone preamp features Gain and Level controls, variable impedance switching, and Instrument DI for recording tone “color”
Improved stability with feedback-style shelving EQ Authentic Teletronix LA-2A-style T4 opto-compressor with continuous peak reduction and makeup gain
Compressor circuitry can be fully bypass with the inclusion of a true bypass switch15dB pad switch and polarity reverse switchImproved metering with meter source selector switchLED jewel “power on” indicator light never needs replacementAuto sensing universal power supplyUA build quality and heritage, audiophile components and hand-assembled in the USAWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 819937000072Mogami Gold Studio XLR Female to XLR Male Microphone Cable (25′, Black)The black, 25′ Mogami Gold Studio XLR Female to XLR Male Microphone Cable is a high-quality, 4-conductor cable engineered for maximum rejection of RFI and EMI, accurate signal transmission with low noise, and durability. It uses the company’s Neglex twisted, double-conductor quad cable with a spiral, bare copper shield, which is effective in maintaining signal integrity, even when used with unbalanced equipment, in professional or home studios suffering from wiring and grounding problems.The cable is terminated with black-body, gold-plated XLR connectors, and features a 0.236″ diameter jacket, ideal for applications where a small-diameter quad mic cable is required.Key FeaturesStudio and broadcast-quality microphone cable wired with Mogami 2534 Neglex twisted quad-conductor cableIdeal for home studios suffering from wiring and grounding problems¡ªmaintains signal quality when used with unbalanced equipmentServed (spiral) bare copper shield for long-lasting protection against RFI and EMIXLPE (Cross-Linked Polyethylene) conductor insulationTerminated with black-body, 3-pin XLR connectors (XLR female to XLR male)Gold-plated contacts to prevent corrosion0.236″ jacket diameter¡ªfor use where a small-diameter quad mic cable is requiredLimited lifetime warrantyWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 801813075847
A2KG C414 XLII Large-Diaphragm Multipattern Condenser Microphone SpecsMicrophonePrimary ApplicationsLive Sound, Studio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserDiaphragm1″ / 25.4?mmPolar PatternCardioid, Figure-8, Hypercardioid, Omnidirectional, Subcardioid/Wide CardioidPattern SelectionSwitched (Adjustable on Mic)OrientationSide AddressCircuitrySolid-StatePad-6 dB-12 dB-18 dBHigh-Pass Filter40 Hz, 12 dB/Octave 80 Hz, 12 dB/Octave 160 Hz, 6 dB/Octave Tone AdjustmentNoneGain AdjustmentNoneIndicators13 x Single LED (Status)On-Board ControlsHigh-Pass Filter, Pad, Polar PatternWindscreenFoam (Included)PerformanceFrequency Range20 Hz to 20 kHz Maximum SPL140 dB SPL (.5% THD)158 dB SPL (.5% THD, with Pad)Impedance200 OhmsLoad Impedance¡Ý 2200 OhmsSensitivity-33 dBV (Open Circuit Voltage)Output Level14 dBV (Max)Dynamic Range134 dB A-WeightedSignal-to-Noise Ratio88 dB A-WeightedEquivalent Noise Level6 dB A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerOperating Voltage44 to 52 V (Phantom Power)Operating Current Consumption4.5 mAPhysicalColorGrayMountingShockmount (Included)Included CaseHard CaseIncluded FiltersPop FilterConstruction MaterialMetalOperating Temperature14 to 140¡ãF / -10 to 60¡ãCDimensionsH: 1.5 x W: 2 x L: 6.3″ / H: 3.8 x W: 5.1 x L: 16?cmWeight10.6?oz / 301?gPackaging InfoPackage Weight4.265 lbBox Dimensions (LxWxH)11.35 x 9.35 x 5.4″Universal Audio LA-610 MKII Recording Channel SpecsNumber of ChannelsSingleInputs1 x XLR Microphone1 x XLR Line Outputs1 x XLRFrequency Response20Hz to 20kHz, +/-0.5dB Noise-72dBu (20Hz to 20kHz, line in/unity gain) PreampGain Range+77dB (microphone)40dB LineMaximum Output+23dBu (120VAC line) Input Impedance500¦¸ or 2k¦¸, selectablePhantom Power+48VCompressorThreshold RangeProgram dependentRatio~3:1, soft knee, program dependentAttack Time~10mSec, program dependentRelease TimeDual stage: ~60mSec for 50% release, followed by 1 to 15Sec, program dependentSlopeNot specified by manufacturerSidechainNoEqualizerFilter TypeLow and high shelf Frequency BandsHF: 4.5, 7 and 10kHzLF: 70, 100 and 200Hz BandwidthNot applicableRange (Boost/Cut)1.5, 3, 4.5, 6, 9dB, switchable boost/cut Threshold RangeProgram dependentRatio~Infinity:1, soft knee, program dependentAttack Time~10mSec, program dependentDe-EsserThreshold RangeNot applicableFrequency RangeNot applicableGateGate ThresholdNot applicableGate RateNot applicablePhysical Power Requirements100/120/240V30W power consumptionDimensions19 x 12.25 x 3.5″ (483 x 311 x 89mm)Weight12 lbs (5.4kg)SpecialtiesCustom Altran and Cinemag transformersAuto sensing universal power supplyPackaging InfoPackage Weight15 lbBox Dimensions (LxWxH)22.2 x 17.4 x 7.3″Mogami Gold Studio XLR Female to XLR Male Microphone Cable (25′, Black) SpecsConnector 1XLR 3-Pin MaleConnector 2XLR 3-Pin FemaleCable Length25′ / 7.6?mOuter Diameter0.236″ / 6?mmShieldingBare Copper SpiralConductor MaterialOxygen-Free Copper (OFC)Number of Conductors4Wire Gauge24 AWGContact PlatingGoldJacket TypePolyvinyl Chloride (PVC)Insulation TypePolyethyleneConductor Capacitance29.6 pF/ft at 1 kHzPackaging InfoPackage Weight1.11 lbBox Dimensions (LxWxH)11.3 x 8 x 1.1″S
