Audix Microphones – How to mic a grand piano with the Audix SCX25A large diaphragm microphoneAudix Microphones – How to mic an acoustic guitar with SCX25A large diaphragm condenser microphoneBuilt for sonically honest recording of vocals and acoustic instruments in studio, live sound, and broadcast applications, the Audix SCX25A is a large-diaphragm cardioid condenser microphone offering a true, open sound devoid of diffractions and acoustic reflections. With its low-profile, lollipop-style form factor, the SCX25A allows optimal placement even when available space is limited. Plus, the mic’s transparent sonic performance makes it well suited for realistic capture of anything from piano and percussion to choirs and orchestras. Thanks to the patented capsule suspension system, the capsule is completely decoupled from the body, so vibrations traveling through the mounts won’t disturb the diaphragm. The SCX25A’s cardioid polar pattern reduces the pickup of bleed from other instruments while producing minimal proximity effect and maintaining consistent tonality on- and off-axis. Capable of accepting SPLs up to 135 dB without distorting, the mic ensures a clean and detailed sound.Ideal for Instrument CaptureAffectionately referred to as “The Lollipop,” the SCX25A cardioid studio condenser microphone is perfectly suited to capture the sound of acoustic instruments such as pianos, guitars, vibes, woodwinds, brass, percussion toys, drums, orchestra, and symphony sections.Patented Capsule Suspension SystemUniquely shock-mounted within an intricate machined brass ring, the 1″ gold vapor capsule is completely isolated from the mic body and electronics. By successfully minimizing acoustic reflections and diffractions, the SCX25A delivers a pure, open-air sound with exceptional detail and realism.Minimal Proximity EffectThe SCX25A is consistent when responding to on and off-axis signals. This mic exhibits outstanding phase coherence and minimal proximity effect. With a wide cardioid polar pattern, the SCX25A enables the sound engineer to blend the sound of the instrument or vocal with the sound of the room. The SCX25A large-diaphragm microphone will handle SPLs in excess of 135 dB and provides up to 20 dB of ambient noise rejection.Features at a GlanceLollipop-style, side-address microphoneLarge-diaphragm capsule with innovative capsule suspension systemPrecision-machined brass body with a multilayer Class-A liquid finishSteel mesh grilleGold-plated XLR 3-pin output connector48V phantom poweredDCLIP snap-on mic clip and foam-lined wooden caseDesigned, machined, assembled, and tested by Audix in the USAWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 687471241134
Audix SCX25A SpecsMicrophonePrimary ApplicationsLive Sound, Studio Recording, BroadcastForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, Instrument, OrchestraSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserDiaphragm1″ / 25.4?mmPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePadNoneHigh-Pass FilterNoneTone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsNoneWindscreenNonePerformanceFrequency Range20 Hz to 20 kHz Maximum SPL135 dB SPL (.5% THD)Impedance200 Ohms at 1 kHzSensitivity28 mV/Pa at 1 kHzDynamic Range121 dBSignal-to-Noise Ratio80 dB Equivalent Noise Level14 dB A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerOperating Voltage48 to 52 V (Phantom Power)PhysicalColorBlackMountingMic Clip/Stand Adapter (Included)Mounting Thread Size5/8″-27 Female (3/8″-16 Female with Included Adapter)Included CaseHard CaseIncluded FiltersNoneConstruction MaterialBrass, Steel Wire GrilleDimensionsH: 0.9 x W: 2 x L: 5.8″ / H: 2.3 x W: 5.1 x L: 14.8?cmWeight8.6?oz / 244?gPackaging InfoPackage Weight2 lbBox Dimensions (LxWxH)9.9 x 6.1 x 4″S
