The black?DPA 4060 CORE is a miniature, moisture-resistant lavalier microphone designed for use with wireless systems for broadcast, performance, and theatrical applications. The electret-condenser capsule delivers crisp, clear, and intelligible speech, while the rugged yet unobtrusive design is well suited to the demands of professional live stage work and presentations.This version of the 4060 uses DPA’s CORE technology to deliver a 6 dB increase in dynamic range and a 6 dB reduction in noise over?the 4060 Legacy model.?The mic includes two interchangeable capsule-protection grids that alter the sonic character of the microphone. The High-Boost Grid creates a peak at 12 kHz, helpful for chest placement, while the Soft-Boost Grid offers a subtle boost between 8 to 20 kHz, lightly enhancing signal presence to ensure clarity.With an SPL rating of 134 dB, the microphone is more than capable of handling most standard speakers, vocalists, and presenters. The mic can also be used very effectively to capture instruments¡ªmaking it a flexible tool for houses-of-worship and live event productions.The 4060 CORE is powered by 5 to 10V plug-in power from a wireless transmitter and features a modular design using a Microdot output connector. The mic is compatible with various wireless microphone transmitters via a separately available adapter for the compatible transmitter. This lavalier kit includes an XLR adapter for use with a wide variety of professional equipment. The adapter allows the mic to be powered via 12 to 48V of external phantom power. Also included is a zippered case, a plastic case, and a lapel clip.Modular System Featuring Microdot Connector with Adapter OptionsCompatible Wireless TransmittersVarious:?Works with various transmitters via a compatible adapter (available separately). The modular design allows you to adapt the 4060’s Microdot connector to a wide variety of transmitters simply by purchasing the compatible adapter¡ªsaving you the expense of buying another microphone.Included XLR Adapter for Wired ApplicationsThe DAD6001 Microdot to 3-pin XLR Adapter allows you to power the 4060 from 12 or 48V phantom power for wired applications.A Reliable, Broadcast-Quality LavalierMiniature Mic with a Crisp, Clear SoundThe 4060 CORE features a 5.4mm capsule that enables the microphone to be inconspicuous and easily disguised in clothing or costumes. The vertical diaphragm design offers a clear and natural sound optimized for the human voice.Two Boost Grids Included to Tailor High FrequenciesThe pre-fitted Soft-Boost Grid gives a 3 dB soft boost at 8 to 20 kHz range. It should be used when the microphone is mounted on the performer’s head as well as in most other applications where you need a natural-sounding mic. Alternatively, the High-Boost Grid introduces a 10 dB boost around 12 kHz for applications where chest-placement is preferred. Both grids are made of tough and scratch-resistant anodized stainless steel, allowing them to be detached and cleaned.Normal Headroom for Standard SpeechThe 4060 CORE features a sensitive capsule designed for standard speech and vocal applications at levels up to 134 dB SPL before clipping.Omnidirectional Polar PatternThe forgiving omnidirectional pickup pattern captures sound from all around the mic and provides a consistent frequency response, even for off-axis sound. This helps to supply clear, intelligible speech and vocals, even when the talent turns away from the microphone.Tough, Moisture-Resistant ConstructionEngineered with a double-vent protection system, the 4060 is certified IP58 for dust and moisture resistance. The rugged 5.9′ cable is built with Kevlar strain relief to survive the constant twists, bends, and pulls that are part of everyday use in harsh environments.Additional OptionsThis version of the DPA 4060 CORE includes a lapel clip, and additional mounting options are available separately.The SCM0032-B 2-Way Dual Clip allows you to mount two lavs for broadcasting.The SCM0013-B 4-Way Clip offers a variety of flexible positioning choices for up, down, left, and right mounting.To hide the mic, the?DMM0021?Concealer attaches safely and securely to clothing and costumes and is designed to resist clothing and rustling noise.Foam windscreens to reduce breath and plosive noises are available in multiple colors choices to match clothing.
DPA Microphones d:screet Core 4060 SpecsMicrophonePrimary ApplicationsLive Sound, Studio Recording, Broadcast, ENG (Electronic News Gathering), Audio for Video, Location Sound, Corporate PresentationForm FactorLavalierIntended Sound SourcesVocals, Acoustic Guitar, Acoustic Bass, Flute, Strings, Violin, Viola, CelloSound FieldMonoOperating PrinciplePressure OperatedCapsuleCondenserDiaphragm0.2″ / 5.4?mm Polar PatternOmnidirectionalHigh-Pass FilterYesGain AdjustmentNoneWindscreenFoam (Available Separately)PerformanceFrequency Range20 Hz to 20 kHz Maximum SPL129 dB SPL Peak (Plug-In Power, 1% THD)134 dB SPL Peak (Plug-In Power, 10% THD)Impedance40 OhmsSensitivity20 mV/Pa at 1 HzDynamic Range106 dB A-WeightedSignal-to-Noise Ratio71 dB A-WeightedEquivalent Noise Level35 dB ITU-R 468THD< 1% ConnectivityOutput Connectors (Analog)1 x Microdot Coaxial Male (Locking, on Mic)Headphone ConnectorNoneCable Length5.9' / 1.8?mPowerBus PowerNoneOperating Voltage5 to 10 V (Plug-In Power)12 to 48 V (Phantom Power)Operating Current Consumption1.5 mAPhysicalColorBlackMountingAlligator Clip (Included)Included CaseHard Case, Zipper PouchIncluded FiltersNoneOperating Temperature-40 to 113¡ãF / -40 to 45¡ãCWeight0.26?oz / 7.5?gPackaging InfoPackage Weight0.58 lbBox Dimensions (LxWxH)9.1 x 5.5 x 1.6"S
