Nevio Passaro about the TLM 102Bundled with a space-saving stand mount, the nickel Neumann TLM 102 large-diaphragm condenser microphone brings renowned Neumann sound quality to a price point that’s inclusive to home producers, working musicians, and independent singer-songwriters. The capsule’s high SPL rating of 144 dB permits the recording of percussion, drums, amplifiers, and other loud sound sources clearly and without distortion. With its 8 to 12 kHz treble boost, the TLM 102 imparts a silky vocal presence while avoiding pronounced sibilance. The mic utilizes a cardioid polar pattern to provide directional sound pickup in front of the capsule and strong rejection behavior behind it, yielding less background noise than most other polar responses. The integrated pop shield reduces breath noise and vocal plosives, though external pop filters are available for even more control. The TLM 102’s transformerless output stage aids the mic in achieving a clean character with plenty of reach in the bass range, and it delivers resistance to electromagnetic interference.Silky ToneNeumann developed the TLM 102 as a universal talent for vocal and instrumental recordings. Its finely tuned sound signature especially accents the area of 8 to 12 kHz which is crucial for human voices. The recordings get a silky elegance typical of large-diaphragm microphones; the voice gets a noble presence in the overall mix. Nevertheless, the TLM 102 remains easy to handle and deals masterfully with critical consonants or sibilants, thanks to the integrated pop shield.No Problem with High VolumeThe TLM 102 also processes extreme volume and jumps in dynamics without distortion. That makes it an excellent choice for miking loud amps and drums. It reproduces sound pressure levels of up to 144 dB (e.g. very loud trumpet at a distance of about 4″) with great clarity: open, detailed, with powerful bass and refined treble.Neumann Sound on a BudgetThe TLM 102 stands for legendary sound on a budget. Neumann remodeled the production and omitted non-vital functions such as pattern, pad, and low-cut switches. When you hear the TLM 102, you’ll immediately notice what they did not omit: the Neumann sound, which remains faithful to its big role models.Clear and PowerfulThe TLM series works with a transformerless output stage to enable a clean and direct sound, very “close” to the acoustic source, and a powerful bass transmission all the way down to the lowest frequencies. Its transformerless output stage also makes the microphone resistant to electromagnetic fields and minimizes transmission losses.Features at a GlanceEasy handling for vocal and instrumental recordingsDistortion-free sound even at extreme sound pressure levels up to 144 dBSlight treble boost for silky vocals (independent of music genre)Built-in pop shield reduces vocal plosivesCardioid polar pattern lessens background noiseXLR 3-pin outputRequires 48V phantom powerIncludes stand mountWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 615104086265
Neumann TLM 102 Large-Diaphragm Cardioid Condenser Microphone (Nickel) SpecsMicrophonePrimary ApplicationsStudio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePadNoneHigh-Pass FilterNoneTone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsNoneWindscreenBuilt-InPerformanceFrequency Range20 Hz to 20 kHz Maximum SPL144 dB SPL (.5% THD)Impedance50 OhmsLoad Impedance1000 OhmsSensitivity11 mV/Pa at 1 kHz into 1 KilohmsOutput Level13 dBu (Max)Signal-to-Noise Ratio73 dB CCIR82 dB A-WeightedEquivalent Noise Level21 dB CCIR12 dB A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerOperating Voltage48 V ¡À 4 V (Phantom Power)Operating Current Consumption3.5 mAPhysicalColorNickelMountingMic Clip/Stand Adapter (Included)Included CaseNoneIncluded FiltersNoneDimensions?: 2 x L: 4.6″ / ?: 5.2 x L: 11.6?cmWeight0.46?lb / 210?gPackaging InfoPackage Weight1.075 lbBox Dimensions (LxWxH)9.95 x 4.35 x 2.85″Rycote InVision Studio Kit with USM SpecsGeneralMicrophone Diameters0.70 to 2.16″ / 18 to 55 mmMax Microphone Length11.8″ / 300 mmMax Vertical Weight1.65 lb / 750 gMax Horizontal Weight1.10 lb / 500 gMax Suspension Rotation175¡ãWeight & DimensionsDimensions5.11 x 9.44 x 6.10″ / 130 x 240 x 155 mmWeight0.13 lb / 61 gPackaging InfoPackage Weight0.95 lbBox Dimensions (LxWxH)7.6 x 6.3 x 5.8″Warm Audio Premier Series Balanced XLR Cable (15′) SpecsConnector 11 x XLR 3-Pin Male StraightConnector 21 x XLR 3-Pin Female Contact PlatingGoldCable Length15′ / 4.6?mPackaging InfoPackage Weight0.8 lbBox Dimensions (LxWxH)9.65 x 8.55 x 2.5″Auray RF-C20 Studio Isolation Filter (Red Composite, Metal Back) SpecsFilter TypeReflection FilterFilter MaterialFoam, MetalMaterial of ConstructionAluminum, Composite FiberDimensions14.6 x 17.5 x 13.3″ / 37.2 x 44.5 x 33.8?cmWeight8.2?lb / 3.7?kgPackaging InfoPackage Weight11.8 lbBox Dimensions (LxWxH)19.5 x 17 x 13″Auray RFMS-580 Reflection Filter Tripod Mic Stand SpecsStandHeight42 to 68″ / 106.68 to 172.72?cmCollapsed Size35.2″ / 89.41?cmGeneralWeight5.2?lb / 2.36?kgPackaging InfoPackage Weight5.8 lbBox Dimensions (LxWxH)35.75 x 5 x 4.25″S
