Home FM/TV Broadcast FM Transmitter 50W FM Transmitter
Trident Audio 88C-40 Series 88 Analog Recording Console with Meter Bridge (40-Channel)
Trident Audio 88C-40 Series 88 Analog Recording Console with Meter Bridge (40-Channel) $93,750.00
Back to products
150W FM Transmitter
150W FM Transmitter $795.00
50W FM transmitter
50W FM transmitter
50W FM transmitter
Click to enlarge
50W FM transmitter
50W FM transmitter
50W FM transmitter

50W FM Transmitter

$550.00

Add to wishlist
Share:
  • Description
  • Additional information
  • Shipping & Payment
Description

Overview

This 50W FM transmitter adopts the concept of simple design and integrates the exciter and power amplifier, output filter, switching power supply, etc into a 1U high 19-inch standard case. This advanced design reduces the number of connection cables and improves the overall efficiency of the 50W FM transmitter, making it more reliable and easier to operate. This 50W FM transmitter has large LCD screen, one-knob control operation, PLL digital phase-locked loop FM technology, CD sound quality. 1U 19-inch all-aluminum standard case. This 50W FM transmitter can input analog audio signal or analog modulation signal. with stable and reliable performance, high quality with fair price.

Functional features

•  Humanized digital LCD panel, one-rotary knob control.
•  User-friendly digital LCD panel, using one rotary knob to easily control all the setups.
•  The integrated LCD screen displays all the parametric including: transmitter frequency, stereo and mono, volume, amplifier tube temperature, audio signal UV meter, forward
power, reflected power, modulation mode, pre-emphasis etc,.
•  1U 19-inch thickened all-aluminium case, strong and excellent heat dissipation.
•  With built-in high-quality stereo encoder, CD-class sound quality.
•  Outstanding power AGC balance control system, adjustable power output from 0 to 50 watts, and automatic gain power control to maintain output power within set range without drifting.
•  Signal input supports XLR and RCA audio inputs,  and also SCA and RDS signals using the BNC connector AUX.

•  Supports AES-EBU digital signal input, 24Bit 192KHz sampling rate input range, true lossless audio.
•   The RF amplifier uses LDMOS transistors to withstand even severe load mismatch exceeding the 65: 1 VSWR at a 5dB compression point.

Specification

Frequency: 87.5-108MHz,

Frequency step value: 10KHz

Modulation mode: FM, peak deviation ± 75KHz

Frequency stability: <± 100Hz

Frequency stabilization method: PLL phase-locked loop frequency synthesis

RF output power: 0 ~50W  ± 0.5dB

In-band residual wave: <-70dB

Higher harmonics: <-65dB

Parasitic AM: <-79dB

RF output impedance: 50Ω

RF output connector: L16 female    N

RF efficiency:> 78%

Analog audio input: -12dBm ~ + 8dBm

Audio level gain: -15dB ~ 15dB step 0.5dB

Analog audio input impedance: 600Ω balanced XLR

AES / EBU input impedance: 110Ω balanced XLR

AES / EBU input level: 0.2 ~ 10Vpp

AES / EBU sampling rate: 30KHz ~ 192KHz 24BIT

RDS / SCA input: unbalanced BNC

RDS / SCA input level gain: -15dB ~ 15dB step 0.5dB

Pre-emphasis: 0μs, 50μs, 75μs (users can set)

Frequency response: ± 0.1dB 30 ~ 15000Hz

Stereo resolution:> 60dB

S / N ratio stereo:> 70dB 30 ~ 15000Hz

S / N ratio mono:> 75dB 30 ~ 15000Hz

Audio distortion: <0.05%

Power supply voltage range: single phase   110 ~ 260Vac

Power consumption:   <200VA

Operating temperature range: -20 to 45 ° C

Working method: continuous work

Cooling method: forced air cooling

Cooling method: <95%

Altitude: <4500M

Dimensions: 483 x 320 x 88 mm (excluding handles and protrusions), standard rack 19 inches 2U.

Weight:  10Kg
