AKG on stage – Funky Song – AKG D112, C519, C1000, C214, P170, D40, P220, IVM4Mic Roundup Part 3: Little Brother Mic LineupThe versatile matched pair of AKG C214MP Large-Diaphragm Condenser Microphones is designed to record lead vocals, drums, acoustic instruments, and guitar amplifiers in the studio, on stage, or in broadcasting situations. Conceived as a cost-effective alternative to the renowned C414 microphone, these microphones use the same 1″ capsule but in a single-diaphragm, cardioid-only configuration. The transducer features technology that allows the membrane to vibrate freely, resulting in a wide frequency range and detailed transients, even at high sound-pressure levels.With the additions of a switchable -20 dB pad and a 160 Hz low-cut filter, the C214 is well suited for close-miking applications as well as overhead placement. The C214 is a rugged microphone built to withstand the severities of professional studios or the road. The integrated capsule suspension helps reduce mechanical noise and resonance for a cleaner sound. The die-cast metal body with shock- and scratch-resistant finish features a double-mesh grille which protects the capsule and ensures efficient rejection of RF interference without affecting acoustics. The pair of C214 comes with a metal carrying case, two stand adapters, and two spider-type shockmounts.?Sonic Character of the C414AKG’s legendary C414 needs no introduction as it is a tool found in most recording studios and has been used on thousands of hit records. Plus, it has been on stage withartists of every musical genre and is also used by leading broadcast facilities the world over. The C214 is designed as a cost-effective alternative to the high-end, industry-leading C414 family. This microphone uses the same 1″ dual-capsule as the legendary C414 in a single-diaphragm, cardioid-only design, giving it performance close to that of the C414.Low Noise and High Dynamic RangeThe C214 has AKG’s legendary large-diaphragm sound and is capable of incredible 143 dB dynamic range for uncompressed, life-like transients while delivering low self-noise of 13 dBA. The C214’s edge-terminated capsule delivers a highly detailed, up-front sound that brings out nuances of any voice or instrument.Pad and Low-Cut FilterThanks to its switchable -20 dB attenuation pad and 160 Hz low-cut filter, the C214 can be used in sound fields as high as 156 dB SPL. So, it can be used on stage for close-up miking for even very loud applications like drum overheads, guitar amps, or high-output brass.Integrated SuspensionThe C214 features an integrated capsule suspension that reduces mechanical noise and resonances for even greater sonic accuracy. The double mesh, all-metal grille protects the capsule and ensures high RF immunity without affecting acoustical performance.Rugged ConstructionThe C214 has a roadworthy construction quality with a scratch-resistant finish, a dent-resistant metal grille, and a gold-plated XLR output.Features at a GlanceCost-effective alternative to the C414 familySame capsule as C414 B-XLS in a single-diaphragm, cardioid-only designCardioid polar pattern reduces pickup of stage bleed and room ambience143 dB dynamic range (pad on)156 dB maximum SPL (pad on)Switchable -20 dB pad and 160 Hz low-cut filterIntegrated capsule suspension to reduce mechanical noiseRugged double-mesh grille for RF immunity but unaffected acousticsOperates on 48V phantom power (accepts 12 to 52 VDC phantom power)Spider-type shockmounts and metal carrying case includedAll-metal die-cast body with shock- and scratch-resistant finishDesigned, engineered, and built in Vienna, AustriaWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 885038025849
AKG C214 SpecsMicrophonePrimary ApplicationsLive Sound, Studio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserDiaphragm1.0″ / 25.40?mmPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePad-20 dBHigh-Pass Filter160 Hz, 6 dB/Octave Tone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsHigh-Pass Filter, PadWindscreenNonePerformanceFrequency Range20 Hz to 20 kHz Maximum SPL136 dB SPL156 dB SPL (with Pad)Impedance200 OhmsLoad Impedance1000 OhmsSensitivity-34 dBVDynamic Range123 dB A-Weighted (without Pad)143 dB A-Weighted (with Pad)Signal-to-Noise Ratio81 dB A-WeightedEquivalent Noise Level13 dB A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerBus PowerNoneOperating Voltage12 to 52 V (Phantom Power)Operating Current Consumption2 mAPhysicalMountingMic Clip/Stand Adapter, Shockmount (Included)Included CaseHard CaseIncluded FiltersNoneConstruction MaterialMetalOperating Temperature14 to 140¡ãF / -10 to 60¡ãCDimensionsH: 1.7 x W: 2.1 x L: 6.3″ / H: 4.3 x W: 5.3 x L: 16?cmWeight9.88?oz / 280?gPackaging InfoPackage Weight5.195 lbBox Dimensions (LxWxH)15.6 x 12.3 x 4″S
