The Audio Technica AT4040 Condenser Microphone with Preamp & Cable Kit from UNCUCO features an AT4040 large-diaphragm cardioid condenser microphone, a Focusrite ISA One microphone preamp, and a premium XLRF-to-XLRM microphone cable. The kit has everything you need for vocal recordings and is also suitable for recording instruments such as pianos, guitars, strings, and more.The AT4040’s side-address condenser mic has a large diaphragm that is tuned to provide a smooth, natural sonic characteristic. Its cardioid polar pattern effectively minimizes off-axis signal, which reduces ambient and residual noise, and offers a wider dynamic range and high-SPL capability.The ISA One microphone preamplifier with a Lundahl input transformer, (essentially the same circuit as the ISA110), has been used for 30 years and imparts a character to the sound that is ideal for use with classic microphones. In addition, four carefully selected impedances allow you to match the microphone to input sources in different ways that bring out more distinctiveness.Audio-Technica AT4040 Large-Diaphragm Cardioid Condenser MicrophoneBoasting a large-diaphragm true condenser capsule, transformerless circuitry, and specially designed physical elements all working together to deliver clean, clear, and smooth sonic performance far outside its price class, the Audio-Technica AT4040 presents itself as a capable microphone for instrument and vocal capture in the studio, at home, or on stage. The large-diaphragm condenser capsule incorporates a cardioid polar pattern for minimal feedback and off-axis noise, a welcome trait when tracking in untreated rooms. Plus, the supplied custom shockmount helps keep extraneous handling and foot noise down.
Engage the -10 dB pad to increase headroom and capture incredibly loud sources¡ªdrums, blaring horns, and guitar cabs¡ªup to 155 dB SPL without distortion. When low-frequency rumble/hum or overwhelming bass invade your signal, turn on the 80 Hz high-pass filter switch to attenuate the lows without resorting to EQ. Since the AT4040 is a solid-state condenser with an XLR output, it should be mated to an XLR-equipped mic preamp capable of sending 48V phantom power. It comes with a protective storage case and a dust cover.For Studio and StageA marriage of technical precision and artistic inspiration, the AT4040 offers exceptionally low noise, wide dynamic range, and high SPL handling for optimal versatility. This ultra-consistent microphone may be used with confidence in a wide variety of studio and live miking applications, even under the stringent demands of digital recording systems.True Condenser CapsuleThe AT4040 side-address condenser microphone features an advanced large diaphragm tensioned specifically to provide smooth, natural sonic characteristics. It boasts an externally polarized (DC bias) true condenser design.Transformerless CircuitryThe AT4040’s low-noise circuitry is symmetrical and transformerless, resulting in fast transient response and clean output signals for transparent reproduction of even the most troublesome of instruments and sound effects.Cardioid Polar PatternThe cardioid polar pattern effectively minimizes off-axis signal, reducing residual noise caused by instruments, ambience, and background noise.Selectable SettingsEquipped with a switchable 80 Hz high-pass filter and -10 dB pad, the AT4040 easily handles high sound pressure levels (up to 155 dB) and avoids the pickup of low-frequency ambient noise (such as traffic, air-handling systems, etc.), room reverberation, and mechanically coupled vibrations.Custom ShockmountThe AT4040 features the AT8449a shockmount, providing maximum protection against noise caused by shock and handling of the microphone and stand.Features at a GlanceTechnically advanced large diaphragm tensioned specifically to provide smooth, natural sonic characteristicsExternally polarized (DC bias) true condenser designExceptionally low noise, wide dynamic range, and high SPL handlingTransformerless circuitry virtually eliminates low-frequency distortion and provides superior correlation of high-speed transientsPrecision-machined, nickel-plated brass, acoustic element baffle provides enhanced element stability and optimal sensitivityOpen acoustical environment of the symmetrical housing assembly minimizes unwanted internal reflectionsState-of-the-art surface-mount electronics ensure compliance with A-T’s stringent consistency and reliability standardsCustom shockmount provides superior isolationSwitchable 80 Hz high-pass filter and -10 dB padOperates on 48V phantom powerXLR 3-pin output connectorWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 042005127955Focusrite ISA One Portable Desktop Microphone PreampThe ISA One from Focusrite is a single-channel, transformer-based microphone preamp, based on the original ISA 110 preamp that formed the cornerstone of each channel of the legendary Forte console. It features classic vintage topology and includes the Lundahl L1538 transformer and a custom Zobel network.In addition to switchable input impedance settings for the microphone preamp, the unit includes a line input on XLR and 1/4″ TRS phone jacks. An independent DI channel features a dedicated gain control, active or passive impedance switch, a 1/4″ TRS output for routing to an amplifier, and an independent XLR output on the rear.The ISA One features an insert point should the need arise to place extra signal processing between the preamp or DI, and the optional analog-to-digital converter. Phantom power, phase reverse and a 75 Hz, 18 dB/octave high-pass filter are also available from the angled front fascia.Independent input metering for both channels is provided by a moving coil VU meter with variable calibration to suit analog and digital recording media, alongside two six-LED peak meters. Inputs can be metered either pre or post insert. The meter calibrations utilize the same reference points as Avid’s Pro Tools HD systems, allowing effortless integration with Pro Tools.A premium bonus is the Brainworx bx_console Focusrite SC channel-strip plug-in, a stellar digital emulation of the legendary and rare Focusrite Studio Console. Only 10 of the consoles were ever produced, but you can access its famed sound directly in your DAW.Classic single-channel Focusrite microphone preamp with Independent DI
Ideal for both engineers and demanding performers alike, featuring independent gain control, an output for routing to an amp, an independent XLR output on the rear and routing to the optional ADCFour, carefully selected, switchable input-impedance levels (including the original ISA 110 setting), to match or enhance the performance of any microphone
Headphone output with volume control can feed either a sum of the two inputs to the headphones output, or an external stereo cue mix (such as a stereo mix feed from an interface) via two TRS Jack inputs on the rear of the unit
Optional stereo 192 kHz analog-to-digital conversion card utilizes cutting-edge conversion technology and Focusrite analog circuitry to deliver the highest A/D performance with a dynamic range of 119 dBDedicated insert point allows the user to place extra processing such as an EQ or compressor, between the preamplifier or DI and the optional converterIncludes Brainworx bx_console Focusrite SC channel-strip plug-in, a stellar digital emulation of the legendary and rare Focusrite Studio ConsoleWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 815301005100Kopul Premium Performance 3000 Series Neutrik XLR Male to XLR Female Microphone Cable (20′, Black)The black Kopul Premium Performance 3000 Series XLR Male to XLR Female Microphone Cable (20′) is designed to be an extremely quiet and flexible cable that is ideal for the most demanding live sound and performance applications. The cable is engineered to be durable and provide protection against EMI, RFI, and static noise. While the cable’s color-coding affords the ability to quickly differentiate between multiple connections on stage, it provides a pleasant aesthetic quality at the same time.Premium Performance 3000 Series cables are made from 24-AWG OFC copper wire that’s wrapped with PE insulation and a conductive PVC inner shield. A cotton-yarn inner layer helps reduce electrostatic and microphonic noise. The 95% dual-spiral shielding makes the cable resistant to EMI and RFI noise. The Neutrik XX silver connectors provide a high level of connectivity, and all the solder connections are shrink-wrapped for protection.95% dual-spiral shielding offers protection from EMI and RFI noiseTwin conductive PVC inner shielding provides 100% coverage of the core conductor. It helps keep the cable’s signal from radiating and affecting nearby cables and helps prevents external EMI from penetrating to the cable’s core24-AWG oxygen-free stranded copper inner core provides the best possible conductivityCotton yarn reduces electrostatic and microphonic noiseAll solder points shrink-wrapped for protectionNeutrik XX silver connectors offer high conductivityCaged type contact and improved ground contactWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 847628558304
Audio-Technica AT4040 Large-Diaphragm Cardioid Condenser Microphone SpecsMicrophonePrimary ApplicationsLive Sound, Studio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, Speech/Voice Over, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleCondenserPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePad-10 dBHigh-Pass Filter80 Hz, 12 dB/Octave Tone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsHigh-Pass Filter, PadWindscreenNonePerformanceFrequency Range20 Hz to 20 kHz Maximum SPL145 dB SPL (1 kHz, 1% THD)155 dB SPL (1 kHz, 1% THD, with Pad)Impedance100 OhmsSensitivity-32 dBV/PaDynamic Range133 dB (1 kHz, at Max SPL)Signal-to-Noise Ratio82 dB (1 kHz)Equivalent Noise Level12 dB SPL A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerOperating Voltage48 V (Phantom Power)Operating Current Consumption4.2 mAPhysicalColorBlackMountingShockmount (Included)Included CaseHard Case, Mic SockIncluded FiltersNoneDimensions?: 2.1 x L: 6.69″ / ?: 5.3 x L: 16.99?cmWeight12.7?oz / 360?gPackaging InfoPackage Weight3.155 lbBox Dimensions (LxWxH)11.5 x 9.9 x 4.35″Focusrite ISA One Portable Desktop Microphone Preamp SpecsNumber of ChannelsSingleInputs1 x XLR Microphone
1 x XLR Line
1 x 1/4″ TRS phone Line
1 x 1/4″ TRS phone Instrument
1 x 1/4″ TRS phone External Input
1 x 1/4″ TRS phone Cue Left
1 x 1/4″ TRS phone Cue Right
1 x 1/4″ TRS phone ReturnOutput1 x XLR Line1 x XLR DI1 x 1/4″ TS DI Thru1 x 1/4″ TRS phone Send1 x 1/4″ TRS phone HeadphonePhantom Power48VMulti FunctionNoGain RangeMic: 0 to 60 dB in 10 dB steps with 20 dB of variable gain
Line: -20 to +10 dB in 10 dB steps with 20 dB of variable gainMaximum Output LevelNot specified by manufacturerFrequency Response16Hz to 118kHz, -3.0dB at maximum gainNoiseMic SNR: 106 dB
Line SNR: 120 dBDimensions8.7 x 10 | 11.4 x 4.1″ / 22 x 25.4 | 29 x 10.4 cmWeight8.6 lb / 3.9 kgPackaging InfoPackage Weight12.9 lbBox Dimensions (LxWxH)16.2 x 15.5 x 9.3″Kopul Premium Performance 3000 Series Neutrik XLR Male to XLR Female Microphone Cable (20′, Black) SpecsCable Length20′ / 6.1?mShielding95% SpiralWire Gauge24 AWGContact PlatingSilverPackaging InfoPackage Weight0.765 lbBox Dimensions (LxWxH)11.6 x 11.2 x 1.15″S
