Mic Shootout 2: Affordable Large Diaphragm CondensersBoasting a dual-diaphragm condenser capsule with three polar patterns, transformerless circuitry, and specially designed physical elements all working together to deliver clean highs and mids along with rich low-end traits, the Audio-Technica AT4050 presents itself as a highly versatile microphone for instrument and vocal capture in the studio, at home, or onstage. The vapor-deposited gold diaphragms are pre-aged to stay sonically consistent over time, while the transformerless circuitry minimizes low-end breakup and contributes to enhanced transient response. Additionally, the precision-machined acoustic baffle yields increased stability.Engage the -10 dB pad to increase headroom and capture incredibly loud sources¡ªdrums, blaring horns, and guitar cabs¡ªup to 159 dB SPL without distortion. When low-frequency rumble/hum or overwhelming bass invade your signal, turn on the 80 Hz high-pass filter switch to attenuate the lows without resorting to EQ. Since the AT4050 is a solid-state condenser with an XLR output, it should be mated to an XLR-equipped mic preamp capable of sending 48V phantom power. It comes with a vibration-mitigating shockmount, a protective storage case, and a dust cover.A Condenser for All OccasionsWith three switchable polar patterns, the large-diaphragm Audio-Technica AT4050 exhibits a remarkable combination of qualities¡ªhigh-SPL capability with transparent airy highs, and mids complemented by rich low-end qualities.True Condenser CapsuleThe AT40540 side-address condenser microphone features dual large diaphragms that are gold-vaporized and aged in house for consistent, outstanding performance. It boasts an externally polarized (DC bias) condenser design.Transformerless CircuitryThe AT4050’s low-noise circuitry is transformerless, resulting in fast transient response and clean output signals for transparent reproduction of even the most troublesome of instruments and sound effects.Three Polar PatternsThe availability of three polar patterns at the flip of a switch allows the AT4050 to serve studios as a versatile all-around workhorse.The omnidirectional polar pattern is sensitive to sound coming from all directions. Select the omni pattern to pick up several voices or instruments on the same microphone, to diminish proximity effect, and to preserve the location¡¯s ambient sound.The cardioid polar pattern is more sensitive to sound originating directly in front of the element, making it useful in controlling feedback, reducing pickup of unwanted sounds and providing isolation between performers.The figure-8 polar pattern is more sensitive to sound originating in the front and back of the microphone, rejecting sounds from the sides. It is often used in conjunction with advanced stereo miking techniques.Selectable SettingsEquipped with a switchable 80 Hz high-pass filter and -10 dB pad, the AT4050 easily handles high sound-pressure levels (up to 159 dB) and avoids the pickup of low-frequency ambient noise (such as traffic, air-handling systems, etc.), room reverberation, and mechanically coupled vibrations.Custom ShockmountThe AT4050 features the AT8449a shockmount, providing maximum protection against noise caused by shock and handling of the microphone and stand.Features at a GlanceTransparent uppers/mids balanced by rich low-end qualities combine with advanced acoustic engineering for extensive performance capabilitiesExternally polarized (DC bias) true condenser design with dual diaphragms to maintain precise polar pattern definition across the full frequency range of the microphone2-micron, vapor-deposited gold diaphragms undergo a five-step aging process, so the optimum characteristics achieved remain constant over years of useOmnidirectional, cardioid, and figure-8 polar patternsExceptionally low noise, wide dynamic range, and high SPL handlingTransformerless circuitry virtually eliminates low-frequency distortion and provides superior correlation of high-speed transientsPrecision-machined, nickel-plated-brass, acoustic-element baffle provides enhanced element stability and optimal sensitivityOpen acoustical environment of the symmetrical housing assembly minimizes unwanted internal reflectionsState-of-the-art surface-mount electronics ensure compliance with A-T’s stringent consistency and reliability standardsCustom shockmount provides superior isolationSwitchable 80 Hz high-pass filter and -10 dB padOperates on 48V phantom powerXLR 3-pin output connectorWhatsApp:+8615989288128 , UNCUCO Radio / TV Studio Equipment. , 042005103164
Audio-Technica AT4050 SpecsMicrophonePrimary ApplicationsStudio RecordingForm FactorLarge Diaphragm Mic / Stand/Boom MountIntended Sound SourcesVocals, InstrumentSound FieldMonoOperating PrinciplePressure GradientCapsuleElectret CondenserPolar PatternCardioid, Figure-8, OmnidirectionalPattern SelectionSwitched (Adjustable on Mic)OrientationSide AddressCircuitrySolid-StatePad-10 dBHigh-Pass Filter80 Hz, 12 dB/Octave Tone AdjustmentNoneGain AdjustmentNoneIndicatorsNoneOn-Board ControlsHigh-Pass Filter, Pad, Polar PatternWindscreenNonePerformanceFrequency Range20 Hz to 18 kHz Maximum SPL149 dB SPL (1 kHz, 1% THD)159 dB SPL (1 kHz, 1% THD, with Pad)Impedance100 OhmsSensitivity-36 dBV/Pa (Open Circuit Voltage)Dynamic Range132 dB (1 kHz, at Max SPL)Signal-to-Noise Ratio77 dB A-Weighted (1 kHz)Equivalent Noise Level17 dB SPL A-WeightedConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Headphone ConnectorNonePowerBus PowerNoneOperating Voltage48 V (Phantom Power)Operating Current Consumption4.2 mAPhysicalColorBlackMountingShockmount (Included)Included CaseHard Case, Mic SockIncluded FiltersNoneDimensions?: 2.1 x L: 7.4″ / ?: 5.3 x L: 18.8?cmWeight1.12?lb / 0.51?kgPackaging InfoPackage Weight3.465 lbBox Dimensions (LxWxH)11.55 x 9.75 x 4.35″S
