The matched pair of satin nickel Microtech Gefell M 930 includes two large-diaphragm cardioid condenser microphones designed for accurate, pleasing reproduction of vocals and instruments for live stage applications and home, project, and commercial recording studios. Additionally, two mic holders and an ORTF-X/Y combination stereo bracket are supplied for easy positioning in stereo configurations.
The large-diaphragm capsule utilizes a cardioid polar pattern to reduce the pickup of off-axis sound such as room ambience. The transformerless circuitry incorporates a transistor amplifier and produces only 7 dBA of self-noise while maintaining low RFI susceptibility.
The M 930’s high sensitivity, standard 3-pin XLR output connector, and 48V phantom powering method ensure reliable performance with a variety of mic preamps. This mic set also includes two XLR cables and a suitcase for safe storage and transport.For vocals, speaker positions, radio plays, and as a support microphone for recording guitars, keyboard, percussion, wind, and string instrumentsCombines modern large-diaphragm technology with the latest semiconductor circuit technologyCondenser capsules with PE membraneTransistor amplifierSlight treble boost for enhanced clarity and presenceUltralow noise of 7 dBAHandles SPLs up to 142 dBHigh dynamic range of 135 dBBalanced 3-pin XLR output connectorOperates on 48V phantom powerIncludes two mic holders, a combination stereo bracket for ORTF and X/Y configurations, two XLR mic cables, and a suitcase
Microtech Gefell M 930 SpecsMicrophoneForm FactorStand/Boom MountSound FieldMonoOperating PrinciplePressure GradientCapsule1 x CondenserPolar PatternCardioidOrientationSide AddressCircuitrySolid-StatePadNoneHigh-Pass FilterNoneTone AdjustmentNoneIndicatorsNoneOn-Board ControlsNoneWindscreenNonePerformanceFrequency Range20 Hz to 20 kHz Maximum SPL142 dB SPL (.5% THD)Off-Axis Rejection2 dB at 60¡ã>12 dB at 120¡ã>25 dB at 180¡ãImpedance100 OhmsSensitivity21 mV/Pa at 1 kHzOutput Level18 dBu (Max)Dynamic Range135 dBSignal-to-Noise Ratio87 dB A-Weighted (1 kHz)81 dB CCIR (1 kHz)Equivalent Noise Level7 dB A-Weighted13 dB CCIRConnectivityOutput Connectors (Analog)1 x XLR 3-Pin Male (on Mic)Cable Length32.81′ / 10?mPowerOperating Voltage48 V (Phantom Power)Operating Current Consumption3.6 mAPhysicalColorNickelMountingMic Clip/Stand Adapter (with Included Hardware)Dimensions?: 1.77 x L: 4.65″ / ?: 45 x L: 118?mmWeight7.41?oz / 210?gPackaging InfoPackage Weight11.91 lbBox Dimensions (LxWxH)17.7 x 14.2 x 6.4″S
